387*330*360mm 2 Cylinder Air Cooled Diesel Engine With ISO9001
Product Details:
| Place of Origin: | WUXI OF China |
| Brand Name: | KAIAO |
| Certification: | CE |
| Model Number: | KA178F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 units |
|---|---|
| Price: | US$166.FOB.Shanghai |
| Packaging Details: | Carton Parkages |
| Delivery Time: | 15 working days |
| Supply Ability: | 10000 units per month |
|
Detail Information |
|||
| Name: | Air Cooled Diesel Engine | Bore*Stroke(mm): | 78*62mm |
|---|---|---|---|
| Compression Ratio: | 20 | Rate Speed(rpm): | 3000/3600rpm |
| Start System: | Recoil Start And Electric Start | Net Weight(Kg): | 33Kg |
| Highlight: | 2 Cylinder Air Cooled Diesel Engine,387*330*360mm Air Cooled Diesel Engine,Air Cooled Diesel Engine ISO9001 |
||
Product Description
387*330*360mm 2 cylinder Air Cooled Diesel Engine with ISO9001
Unique Driving System
Adopted designed precise gear driving & balance shaft system to ensure more excellent performance & stable than other makers
Perfect Direct Injection
To realize the ideal match between the combustion chamber and injection system, keep maximum power from every drop of diesel, it’s extraordinarily low fuel consumption & environmentally friendly engine.
Low Vibration & Low Noise
Vibration & Noise reduction is achieved through the adopt of precision balancers. It makes operation comfort even under long working hours.
Compact Design, Quick & Easy Start
With stronger but lightweight alloy used for main engine parts, extra tough crankshaft and overall compact structure, ensure powerful and simple to install and quick & easy to start.
Application:
KAIAO air-cooled single cylinder engines could be assemble with Agricultural machines (such as Tillers), marine boats, generators & pump sets etc.
| Model | KA178F/Single cylinder air-cooled diesel engine |
| Rated output(HP/rpm) | 5HP/3000rpm, 5.5HP/3600rpm |
| Rated output(KW/rpm) | 3.68KW/3000rpm, 4KW/3600rpm |
| Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| Cylinder Diameter*stroke(mm) | 78*62mm |
| Piston displacement (L) | 0.296L |
| Compression ratio | 19 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash complex Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 3.5L |
| Fuel consumption rate(g/kW.h) | 275/3000 280/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 1.65 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | Above 12V-36AH |
| Dimension (L*W*H)(mm) | 520*520*570mm |
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located?
A: Our factory is in Taizhou City, Zhejiang Province, China.
It's near Ningbo & Shanghai port.
It's about 15minutes from Luqiao air port by car, 45 minutes from Wenlin train station by car.
3.Q:What is the material of your products
A: Iron,Steel,plastic,etc.
4.Q:How about quality control in your factory?
A:"Quality is first, Customers are friends".
Taizhou Belten people are always paying great attentions to quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
5.Q:How about guarantee?
A: It's within three months after goods is discharged in the destination.
During that period,if some breakdown easily spare parts need to change,my factory offers free.
For example, fuel cock,spark plug,starting hand,etc.
