Unique Driving System 4000 Watt 1800 Rpm Air Cooled Diesel Engine High Speed
Product Details:
| Place of Origin: | China |
| Brand Name: | KAIAO |
| Certification: | CE/ISO/SGS |
| Model Number: | KA178FS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Cartons |
| Delivery Time: | 10 working days after received down-payment |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 20,000 pcs per month |
|
Detail Information |
|||
| Bore X Stroke (mm): | 78x62 | Name: | Air Cooled Diesel Engine |
|---|---|---|---|
| Fuel Type: | 0#, -10#, -20# Diesel | Lube Oil Type: | CD Grade Or SAE 10W-30, 15W-40 |
| Lube Oil Capacity (L): | 1.1 | Net Weight (KGS): | 33 |
| Starting System: | Manual | Rate Power/Max Power(kw): | 4/4.4 |
| Highlight: | 1800 rpm air cooled diesel engine,4000 watt air cooled diesel engine,50hz small air cooled diesel engine |
||
Product Description
Unique Driving System Air Cooled Diesel Engine High Speed 4000 Watt 1800rpm
| structure | frame type, four small wheel |
| Rated power | 7KW |
| Maximum power | 8KW |
| Rated frequency | 50Hz |
| Rated voltage | 220V |
| Excitation mode | Brush |
| Fuel tank capacity / working time | 12L/5.5 hours |
| Engine type | RZ192FA/E |
| Engine type | single cylinder four stroke air cooling |
| Bore * stroke | 92 * 75 |
| Displacement | 498cc |
| Fuel model | summer 0#, winter -10# |
| Lubricating oil type | SAE15W/30 |
| Lubricating oil capacity | 1.65L |
| Starting mode | hand pull start / electric start |
| Battery capacity | 20Ah |
| Unit size | 720 x 500 x 630(mm) |
| Packing size | 745 x 520 x 655 (carton) |
| Net weight / gross weight | 96/101 |
Unique Driving System
Adopted designed precise gear driving & balance shaft system to ensure more excellent performance & stable than other makers
Perfect Direct Injection
To realize the ideal match between the combustion chamber and injection system, keep maximum power from every drop of diesel, it’s extraordinarily low fuel consumption & environmentally friendly engine.
Low Vibration & Low Noise
Vibration & Noise reduction is achieved through the adopt of precision balancers. It makes operation comfort even under long working hours.
Compact Design, Quick & Easy Start
With stronger but lightweight alloy used for main engine parts, extra tough crankshaft and overall compact structure, ensure powerful and simple to install and quick & easy to start.
Application:
KAIAO air-cooled single cylinder engines could be assemble with Agricultural machines (such as Tillers), marine boats, generators & pump sets etc.
FAQ
A:T/T 30% as deposit,and 70% before loading. We will show you the photos of the products and packages before you pay the balance.
Q2.What your terms of delivery?
A:EXW,FOB,CFR,CIF.
Q3.How about your delivery time?
A:Generally,it will take about 20 days after receipt of deposit payment.The specific delivery time depends on the items and the
quantity of your order.
Q4.Are you interested in dealership with local company?
A:Yes,we are quite interested in this business.we'd like to cooperate with some local partner to sell more truck in local market
and supply better service.
Q5.Do you test all your diesel engine before delivery?
A:Yes,we have 100% diesel engine test and complete quality control system defore delivery.
Q6.How do you make our business long-term and good relationship?
A:1.We keep good quality,competitive price and efficient service to ensure our customers benefit;
2.We protect the benefit of dealer or agent,in specifical period and region.
