30kva / 24kw Deutz Engine Air Cooled Diesel Generator
Product Details:
| Place of Origin: | Wuxi of China |
| Brand Name: | KAIAO |
| Certification: | CE |
| Model Number: | KA178F |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 units |
|---|---|
| Price: | US$165.FOB.Shanghai |
| Packaging Details: | Cartons |
| Delivery Time: | 15 working days |
|
Detail Information |
|||
| Model: | KA178F/single Cylinder Air-cooled Diesel Engine | Type: | Single Cylinder And Four Stroke |
|---|---|---|---|
| Bore*Stroke(mm): | 78*62mm | Displacement(L): | 0.296L |
| Compression Ratio: | 20 | Rate Power(KW): | 3.68KW/4KW |
| Rate Power(HP): | 5HP/5.5HP | Rate Speed: | 3000rpm/3600rpm |
| Fuel Tank(L): | 3.5L | Start System: | Recoil Start And Hand Start |
| Application: | For Mini-tillers,cultivators Use | ||
| Highlight: | 24kw 30 kva air cooled generator,deutz engine air cooled diesel generator,30kva air cooled diesel generator |
||
Product Description
Product Application
Diesel generator is wildly used as prime power or standby power,which is supply in national denfence, telecommunication, fieldwork,building, supermarket, industrial and mining factory, oil field, highway, harbour, countryside and so on.
Unique Driving System
Adopted designed precise gear driving & balance shaft system to ensure more excellent performance & stable than other makers
Perfect Direct Injection
To realize the ideal match between the combustion chamber and injection system, keep maximum power from every drop of diesel, it’s extraordinarily low fuel consumption & environmentally friendly engine.
Low Vibration & Low Noise
Vibration & Noise reduction is achieved through the adopt of precision balancers. It makes operation comfort even under long working hours.
Compact Design, Quick & Easy Start
With stronger but lightweight alloy used for main engine parts, extra tough crankshaft and overall compact structure, ensure powerful and simple to install and quick & easy to start.
Application:
KAIAO air-cooled single cylinder engines could be assemble with Agricultural machines (such as Tillers), marine boats, generators & pump sets etc.
| Model | KA178F/air-cooled diesel engine unit |
| Rated output(HP/rpm) | 5HP/3000rpm, 5.5HP/3600rpm |
| Rated output(KW/rpm) | 3.68KW/3000, 4KW/3600 |
| Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| Cylinder Diameter*stroke(mm) | 78*62mm |
| Piston displacement (L) | 0.296L |
| Compression ratio | 19 |
| Max. no-load speed(r/min) | 108% of Rated rotary speed |
| Min. no-load speed(r/min) | 1300 |
| Lubrication system | Pressure splash complex Type |
| Engine starting system | Recoil starter or Electric starter |
| Output terminal rotation | AnticlockWise |
| Fuel oil model | Summer:0#, Winter:-10# |
| Fuel tank capacity (L) | 3.5 |
| Fuel consumption rate(g/kW.h) | 275/3000 280/3600 |
| Oil consumption rate(g/kW.h) | 4.08 |
| Oil grade | CD grade or SAE10W-30,15W-40 |
| Valve clearance(cold state) mm | 0.10-0.15 |
| Lube oil capacity (L) | 1.65 |
| Starting motor (V,kW) | 12V 0.8kW |
| Charging generator(V,A) | 12V 3A |
| Battery capacity(V,AH) | Above 12V-36AH |
| Dimension (L*W*H)(mm) | 490*430*520mm |
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the generator, training how to use the generator.
* Engineers available to service machinery overseas.
